行業中的佼佼者，解決問題的s4ai多用途揚聲器環繞聲揚聲器。它適合standard-construction2“×4”螺柱與墻格柵安裝沖水的壁面，確保即使toughest-to-please設計師會愛看。偶極子或偶極子模式之間選擇一個壯觀的電影體驗。切換到您喜愛的音樂模式和s4ai變成直接輻射雙向8“喇叭。較小的裝置，在7通道是重要的，但你沒有空間，可以采用雙驅動的s4ai提供兩側和后方通道從一個位置的房間。該s4ai可以用任何的聆聽合成系列系統。
|
Maximum Recommended Amplifier Power
|
200 Watts single-driven or 175 watts-per-array dual-driven
|
|
Nominal Impedance
|
6 Ohms
|
|
Sensitivity (2.83V @ 1m)
|
90dB
|
|
Frequency Response (–3dB)
|
80Hz –20kHz
|
|
Crossover Frequencies
|
Dipole mode: 800Hz, 3.6kHz
Bipole mode: 800Hz, 3.6kHz
Direct mode: 2.5kHz
|
|
High-Frequency Transducers
|
Triple 1" pure-titanium domes with rubber surrounds, shielded, with EOS waveguides
|
|
Midrange Transducer(s)
|
Dual 4" dome with rubber surrounds, neodymium magnet and cast-aluminum baskets
|
|
Low-Frequency Transducer
|
8" Dual-voice-coil inverted dome with rubber surround and cast-aluminum basket
|
|
Connections
|
Speaker: 4-conductor push-type, 10-16 gauge;
Control: 2-conductor screw terminal, 18-24 gauge
|
|
Dimensions
(H x W x D)
|
23-7/8" x 14" x 3-3/4"
(606mm x 356mm x 95mm)
|
|
|
|
|
THX Ultra2™-certified Dipole Surround Loudspeaker
|
|
Installer-Configurable to 8", 3-Way Dipole Operation
|
|
Auto-Switchable to Direct-Radiating Pattern Using 12 Volt Trigger
|
|
Single or Dual Drive Capability; Horizontal or Vertical Orientation; 90°Rotatable Mid/High Array for Use In-Wall or In-Ceiling
|
|
Fits Completely Flush in a Standard 4" Depth Wall or Ceiling
|
|
Factory Configured in 8", 3-Way Bipole Operational Mode
|
|
Integrated One-Piece Back Box
|
|
|
